Long Range Remote Start Only System
Model: PRO9056E
KEY FEATURES
(2) 1-BUTTON LONG RANGE TRANSMITTER
Increased range - up to 1,200 feet of operating range
Glass mount antenna with built-in LED light and valet switch
On board start relay
On board accessory relay
On board ignition 1 & 2 relay
Ignition 2 relay selectable on or off during cranking
On board parking light relay
If You Are Interested in this Unit, Inquire At Your Local Authorized Retailer.
Find Your Replacement Transmitter
PRODUCT OVERVIEW
The PRO9056E is a long range remote start only system that comes with (2) one button long range transmitters with up to 1,200 feet of operating ranges, glass mounted antenna with built-in LED light and valet switch as well as optional door lock and unlock
Features (continued)
- Ignition 3 / shock by-pass / GM VAT output (relay required)
- Tach signal learning circuit
- 2 (+) and 2 (-) safety shutdown circuits
- Alarm by-pass output
- Accessory outputs (pulse before & after start, during crank & after shut down)
- Selectable steady or flashing parking lights for run indication
- Selectable run times
- Optional door unlock feature for vehicles equipped with power doors
- Hybrid vehicle compatible for remote start
- RF Programmable
- Telematics port
- DBI port - plug in FlashLogic by-pass capable
- Limited lifetime warranty - includes nationwide travelers warranty
Specifications
| Range (Distance) | 1,500' | |
| Programmed Transmitter Notification | N/A | |
| Two-Step Unlock | N/A | |
| Parking Light Flasher | Yes | |
| Starter Interrupt Relay | N/A | |
| Starter Interrupt Output | N/A | |
| Plug In Dual Stage Shock Sensor | N/A | |
| Auto Lock/Unlock | N/A | |
| Passive Locks | N/A | |
| Remote Panic | N/A | |
| Horn Output | N/A | |
| Active or Passive Arming Selection | N/A | |
| Push Button LED / Valet / Programming Switch | N/A | |
| Glass Mount Antenna LED/Valet Switch | Yes | |
| Keyless Entry | N/A | |
| Remote Trunk Release | N/A | |
| Dual Vehicle Operation | N/A | |
| Chirp Delete From Transmitter | N/A | |
| Dome Light Illumination Output | N/A | |
| Selectable Run Time 5 - 10 - 15 - 20 - 45 - 60 Minutes | Yes | |
| Can Be Used With Gas or Diesel Engines | Yes | |
| Diesel Wait To Start Input | Yes | |
| Automatic Timed Start | N/A | |
| Ground Output While Running | Yes | |
| 4 Auxiliary Outputs Pulses, Before Start, After Start, During Crank, After Shut Down. | Yes | |
| Safe Start Double Push To Start System | Yes | |
| Hybrid Compatible | Yes | |
| On-Board Relays | 5 | |
| Additional Aux Channel Outputs | N/A | |
| Operates Memory Seats | N/A | |
| Turbo Timer | N/A | |
| Headlight Activation | N/A | |
| Selectable Remote Start Shock Sensor By-Pass | N/A | |
| Door Unlock Capable Under Remote Start Control | Yes | |
| Web Based Programmable | Yes | |
| DBI Port - Flashlogic Ready | Yes | |
| Warranty - Includes Nationwide Travelers | Lifetime | |
| Transmitters | 2 - 1 Button |
