CLICK HERE FOR DOWNLOAD -> OTOMF1_130116.ZIP

All Prior Advent Firmware Updates are included in this version. There is no need to upgrade to any version prior to this before using this firmware.

This update addresses reports of the following issues:

Some users have reported hearing a “pop” sound at shut down

The vehicle backup camera setting defaulting to the OFF position.



All Firmware files are compressed to make it easier and faster to download. When you download this file to your computer you will need a program to uncompress the files. This is called “UNZIPPING”. There are many free programs to do this and your computer may have already come with a program built in to do this. If you require a program we recommend WINZIP.

WINZIP is free and can be downloaded here: http://www.winzip.com/downwz.htm Follow the instructions at the WinZip site for use of this utility. Please follow the instructions below for performing the update to your radio.



NOTE: YOU MUST LOAD THE NEW SOFTWARE ON EACH SD CARD. YOU CAN NOT COPY TO ONE CARD AND UPDATE MULTIPLE RADIO’S. USE THE SD CARD FROM EACH RADIO SEPARATELY.

THE FIRMWARE YOU DOWNLOADED IS SPECIFIC TO THE MODEL RADIO YOU HAVE SELECTED. DO NOT USE IN ANOTHER MODEL OF RADIO. THIS WILL CAUSE IMPROPER OPERATION AND POSSIBLY DAMAGE THE UNIT.

















To update the firmware:

Remove the MAP SD card from the radio. Take note on how it came out, contacts up or down?

You need a Micro SD Card Adapter; this can be purchased at any office supply store. Insert the Micro SD into the adapter and plug it into your computer. This can be a SD Card slot or USB slot depending on your adapter and computer. Do not delete any files or format the SD card. If you do this you will delete the Map from your card. Follow the directions carefully.

Unzip the file you downloaded and copy all files to the MAP Micro SD CARD – This must be done for each radio.

You cannot move one SD card to another vehicle!

If you are asked “File already exists, is it ok to replace, answer “YES” When completed remove the Micro SD from the adapter and return to the vehicle. (This can be done on the bench too.)

Start with the key off. (Or Power off if on the bench)

Insert the updated SD card back into the radio exactly the same way it came out, Make sure it clicks in.

Turn the radio on. Wait for it to boot up. Hit the Menu button, Go to settings and go to the second page, push update system. Wait for the key pad to show up, then enter 543210 and hit the enter/return key (looks like an arrow)
select auto update, select yes to update all. The update will begin running.

Wait until the radio reboots completely and the Radio Screen comes up; do not stop the update,

Next: Select Settings from the main menu, then go to page 2, press and hold SYSTEM RESET UNTIL THE RADIO SHUTS OFF, (this is extremely important) then let the radio reboot.

Your Radio now has all the latest features. You will need to select you user options and reprogram any settings you may have chose previously.

You’re finished. This process should not take more than about 5 or 10 minutes to complete.

This update only updates the Radio Operating system. For Navigational updates go to WWW.NAVIEXTRAS.COM and follow the instructions there.



















FOLLOW BOOTLOADER INSTRUCTIONS BELOW – YOU MUST REPROGRAM THE VEHICLE SELECTION WHEN THE UPDATE IS COMPLETED.





ART_Advent_OE_Logo_BK







OTOMF1 Firmware selection Instructions



The OTOMF1 requires programming to select the year of the installed vehicle. Due to changes in Toyota Vehicles between 2011 and 2012 we have designed this radio to be programmed with multiple configurations. You will need to select the correct one for your vehicle.

DO NOT TURN OFF OR DISCONNECT THE RADIO WHILE UPDATING THE FIRMWARE!

1: Go to the SETTINGS menu, then to page 2 and press the “UPDATE” button.

2: When the keypad appears enter 31521 then press the Enter key ( 8  ). The vehicle selection screen will now load, this may take a moment.

3: Select your vehicle year. Once located press the button that has your vehicle listed on it.

4: “Are you sure” will appear, confirm your selection with YES or NO. If for some reason this radio had been programmed before or you select the wrong choice just turn the radio off then on again and start over.

5: The update will run and when done it will return to the Vehicle Selection screen. Once you are sure the update is completed press the “REBOOT” button.

6: The radio will re-boot to the normal Radio screen. The update has been completed.

NOTE: For DVD video operation all vehicles require the Parking Brake lead be connected to the parking brake switch side that has a ground when the parking brake is engaged. If this is not connected DVD video cannot be played. Always connect correctly as viewing video when driving is illegal and unsafe.

The instructions included in this manual are current at the time of printing. It is designed as a guide and to help make installations easier and faster. Always use caution and ask for assistance if you are not sure on how to proceed. Audiovox is not responsible for any damage that may occur during installation or any changes in vehicle interior.

Any questions, concerns, or issues??? Call Tech Support at 1-800-323-4815

For Tech Tips, Install Notes, or other information go to www.audiovoxuniversity.com.
